agria 3400
Two-wheel tractor
Professional power for your daily work
The agria 3400 single-axle tractor is the proven professional classic in agria's portfolio and combines over 40 years of experience in robust, versatile work machine design. No machine class has earned the designation "all-rounder" as much as the agria single-axle tractor. With its powerful engines, the agria 3400 masters demanding tasks in gardening, landscaping, municipal applications and industry. The innovative 180° rotating Steering handle system enables seamless switching between front and rear attachment, which considerably expands the range of attachments. With the lockable Differential transmission, the agria 3400 can be controlled safely even in extreme situations, but still remains easy to maneuver. The gear-independent PTO system allows the working speed to be gradually adjusted to different conditions, guaranteeing precise and efficient work
The quick coupling system enables tool-free changes between Hoeing attachments, Cutterbars, plows, Kultivators and many other implements. The agria 3400 KL version in particular has single-wheel Lenkbremskuppl. for particularly sensitive cornering maneuvers without loss of speed. The rotating Steering handle can be adjusted in height and sideways without tools, which ergonomically optimizes work on different terrains. With optional electric start, 12 V generator and support foot, the agria 3400 is fully equipped for professional daily use.
Green space maintenance
Grassland maintenance is a core competence of the agria 3400, for which different mowing systems are available. With bar mowers, the agria 3400 is suitable for precise grass cutting on lawns and roadsides, while flail mowers can also cope with denser vegetation. The lockable Differential axle ensures safe handling without the risk of slipping, even on uneven terrain. The smoothest handling of green areas is achieved by choosing between different working speeds of the gear-independent PTO system.
Soil cultivation
The versatility of the agria 3400 is particularly evident in the flexible use of various Attachments for cultivation. Hoeing attachments loosen and break up the soil into fine seedbeds, while Turn ploughs ensure thorough loosening of the subsoil. Single ploughs and Potato digging ploughs also make the agria 3400 suitable for specialized vegetable and potato cultivation work. The rotating Steering handle allows different implements to be used in rear or front cultivation - a flexibility that minimizes processing times. Rotary harrows and Kultivators round off the range for optimum seedbed preparation and weed control.
Grounds care
For area maintenance tasks, the agria 3400 demonstrates its universality, particularly in snow clearing, sweeping and surface cleaning. With optional snow clearing blades and Snow throwers, the agria 3400 becomes a reliable helper in critical winter situations. Sweepers and Weed sweepers turn the single-axle machine into an efficient cleaning machine for paved areas, paths and parking lots. The lockable Differential axle prevents slippery movements during wet work and increases safety. Snow tracks can be optionally mounted to ensure safe maneuverability even in extreme winter conditions.
Machine equipment and information
News
![[Translate to Englisch:]](/fileadmin/_processed_/a/2/csm_2021_agria_3400_Hof_Wessels_1_da6e019652.jpg "[Translate to Englisch:]")
New agria 3400 for Wessels Farm
"Slices through the (still frozen) soil like a knife through butter. We are looking forward to the new vegetable season, to the work with the agria…
Maintenance of paths - Surface conditioner for water-bound surfaces
The surface conditioner is specially designed in order to free water-bound areas such as paths in parks, hiking trails and lanes in cemeteries as…
Technical data
agria 3400 | |
|---|---|
| Item number | 3400 822 |
| Engine | Kohler Command PRO CH395 1-Zylinder 4-stroke petrol engine; 7.1 kW (9.7 hp) |
| Tank capacity | 7.0 liters |
| Gear | 4-speed reversing gearbox in differential version with Locking, 4 V/4 R* |
| Speeds | V/R*: 1.0; 1.9; 3.25 and 7.1 km/h |
| Steering | |
| Single wheel steering brake clutches | - |
| Standard equipment | |
| Steering handle height and sideways adjustable without tools | - |
| Steering handle can be rotated through 180 | - |
| Hand starter | - |
| Electric start with Plug socket | Option |
| Implement coupling | - |
| Generator 12 V | 150 watts |
| Workinghours counter | - |
| Service and parking brake | - |
| Multi truck hubs | - |
| Support foot | - |
| Weight (without Wheels) | approx. 106 kg |
agria 3400 KL | |
|---|---|
| Item number | 3400 837 |
| Engine | Kohler Command PRO CH395 1-Zylinder 4-stroke petrol engine; 7.1 kW (9.7 hp) |
| Tank capacity | 7.0 liters |
| Gear | 4-speed reversing gearbox, 4 V/4 R* |
| Speeds | V/R*: 1.0; 1.9; 3.25 and 7.1 km/h |
| Steering | |
| Independent wheel steering brake clutches | - |
| Standard equipment | |
| Steering handle height and sideways adjustable without tools | - |
| Steering handle can be rotated through 180 | - |
| Hand starter | - |
| Electric start with Plug socket | Option |
| Implement coupling | - |
| Generator 12 V | 150 watts |
| Workinghours counter | - |
| Service and parking brake | - |
| Multi truck hubs | - |
| Support foot | - |
| Weight (without Wheels) | approx. 133 kg |
agria 3400 D | |
|---|---|
| Part number | 3400 415 |
| Engine | Yanmar L100V 1-Zylinder 4-stroke diesel engine 6.8 kW (9.2 hp) |
| Tank capacity | 4.7 liters |
| Gear | 4-speed reversing gearbox in differential version with Locking, 4V/4R* |
| Speeds | V/R*: 1.0; 1.9; 3.25 and 7.1 km/h |
| Steering | |
| Single wheel steering brake clutches | - |
| Standard equipment | |
| Steering handle height and sideways adjustable without tools | - |
| Steering handle can be rotated through 180 | - |
| Hand starter | - |
| Electric start with Plug socket | Option |
| Implement coupling | - |
| Generator 12 V | 180 watts |
| Workinghours counter | - |
| Service and parking brake | - |
| Multi truck hubs | - |
| Support foot | - |
| Weight (without Wheels) | approx. 147 kg |
agria 3400 KL D | |
|---|---|
| Part number | 3400 435 |
| Engine | Yanmar L100V 1-Zylinder 4-stroke diesel engine 6.8 kW (9.2 hp) |
| Tank capacity | 4.7 liters |
| Gear | 4-speed reversing gearbox, 4 V/4 R* |
| Speeds | V/R*: 1.0; 1.9; 3.25 and 7.1 km/h |
| Steering | |
| Independent wheel steering brake clutches | - |
| Standard equipment | |
| Steering handle height and sideways adjustable without tools | - |
| Steering handle can be rotated through 180 | - |
| Hand starter | - |
| Electric start with Plug socket | Option |
| Implement coupling | - |
| Generator 12 V | 180 watts |
| Workinghours counter | - |
| Service and parking brake | - |
| Multi truck hubs | - |
| Support foot | - |
| Weight (without Wheels) | approx. 175 kg |
agria 3400 D | |
|---|---|
| Item number | 3400 416 |
| Engine | Yanmar L100V 1-Zylinder 4-stroke diesel engine 6.8 kW (9.2 hp) |
| Tank capacity | 4.7 liters |
| Gear | 4-speed reversing gearbox in differential version with Locking, 4V/4R* |
| Speeds | V/R*: 1.0; 1.9; 3.25 and 16.9 km/h |
| Fast speed with 16.9 km/h** | - |
| Steering | |
| Individual wheel steering brake clutches | - |
| Standard equipment | |
| Steering handle height and sideways adjustable without tools | - |
| Steering handle can be rotated through 180 | - |
| Hand starter | - |
| Electric start with Plug socket | Option |
| Implement coupling | - |
| Generator 12 V | 180 watts |
| Workinghours counter | - |
| Service and parking brake | - |
| Multi truck hubs | - |
| Support foot | - |
| Weight (without Wheels) | approx. 147 kg |
| Special features | Equipment according to StVZO for trailer operation |
• Standard equipment
- not available
* 3R with single-axle drawbar position
** in single-axle drawbar position for transport only
Videos
F.A.Q. - Frequently asked questions
Search result: 7 Questions
Cleaning the Cutterbar after every Insert is recommended. The blades should be resharpened regularly. The blade clearance must also be checked regularly and readjusted if necessary. The moving parts must be lubricated according to the maintenance schedule. Please refer to the Operating instructions in our Download Center for the exact details.
There are a total of five different versions of the agria 3400.
These differ in terms of Engine variants, Differential, KL and Fast speed for trailer operation.
There are two different engine variants for the agria 3400.
Depending on customer requirements, a Benzin or Diesel version is available.
On a single-axle machine such as the agria 3400, the Steering handle can be rotated by 180* to increase the attachment options for the Implement.
On Implement carriers such as the agria 5900 Bison/Taifun, the Handlebar can only be rotated by 30*, which means that all implements can be operated from the front.
With the agria 3400 Differential version, the Differential can be opened and closed.
When milling, both Wheels should be driven and therefore the Differential should be closed.
When turning and reversing, the Differential should be open to allow Overrunning of the Axle and thus easy operation.
The Handlebar version enables easy steering of the Basic machine.
Here, two additional Steering brakes are mounted on the upper beam, which are used to control the steering movements.
Our Spreader is suitable for: agria 3400, agria 3600, agria 3600 BM, agria 5500 and the agria 5900 series
The agria 3400 KL (curve Steering) are not approved as they are far too dangerous in operation.
When the Steering brake is actuated, the Wheel would lock completely and the single-axle tractor would fold in.
In this case, it is only possible to carry out steering movements by changing direction on the upper beam with the Differential open with the differential version.
Due to constant further development, we reserve the right to make changes to the scope of delivery in terms of form, technology and equipment. No claims can therefore be derived from the information and illustrations. Some product illustrations do not correspond to the delivery version and may contain accessories.
Weight specifications: without fuel, without oil and partly without Set of tires.
